COMPLETE CORN GRINDING & CORN EMBRYO OIL PRESSING PLANT WITH CAPACITY OF 100 MT/DAY
7 TON/DAY CORN EMBRYO SOLVENT EXTRACTION STATION
| Description | Power (kW) | Q-ty | |
|---|---|---|---|
| 1 | Equipment | 23,2 | 47 pcs |
| 2 | Electrical equipment and control system | - | 1 set |
| 3 | Material of installation | - | 1 lot |
| 4 | Instruments and Valves | - | 1 lot |
| TOTAL: | 23,2 |
TOTAL POWER INSTALLED: 23.2KW
WATER CIRCULATION: 20T/H APPROX.
STEAM CONSUMPTION: 300KGS/HOUR APPROX.
SOLVENT RESIDUE IN OIL: 500PPM MAX.
SOLVENT CONSUMPTION: 5KG PER 1MT CAKES MAX. APPROX.
SOLVENT RESIDUE IN MEAL: 700PPM MAX.
OIL RESIDUE IN MEAL: 1.5% MAX.
Equipment Details
| No. | Figure No. | Description | Power (kW) | Qty (pcs) | Dimensions LxBxH (mm) | Weight (kg) | Material |
|---|---|---|---|---|---|---|---|
| 1 | B1 | Condenser | - | 1 | 680x316x580 | 250 | 304/Q235-A |
| 2 | B2 | Condenser | - | 1 | 680x316x580 | 200 | 304/Q235-A |
| 3 | B3 | Solvent Tank | - | 1 | 5600x2000x2200 | 1500 | Q235-A |
| 4 | B4 | Multifunction Extractor | 3 | 1 | 1400x1400x3500 | 800 | Q235-A |
| 5 | B5 | Catcher | - | 1 | 700x500x1200 | 60 | Q235-A |
| 6 | B6 | Miscella Heater | - | 1 | 3000x300x100 | 50 | Q235-A |
| 7 | B7 | Multifunction Extractor | 3 | 1 | 1400x1400x3500 | 800 | Q235-A |
| 8 | B8 | Catcher | - | 1 | 700x500x1200 | 60 | Q235-A |
| 9 | B9 | Miscella Heater | - | 1 | 3000x200x100 | 50 | Q235-A |
| 10 | B10 | Multifunction Extractor | 3 | 1 | 1400x1400x3500 | 800 | Q235-A |
| 11 | B11 | Catcher | - | 1 | 700x500x1200 | 60 | Q235-A |
| 12 | B12 | Miscella Heater | - | 1 | 3000x200x100 | 50 | Q235-A |
| 13 | B13 | Condenser | - | 1 | 1600x1332x700 | 600 | 304/Q235-A |
| 14 | B14 | Solvent Pump | 1,5 | 1 | 800x350x300 | 100 | Q235-A |
| 15 | B15 | Hot Water Pool | - | 1 | - | - | Устанавливается покупателем |
| 16 | B16 | Hot Water Pump | - | 1 | 800x350x300 | 80 | Q235-A |
| 17 | B17 | Miscella Pump | 1,5 | 1 | 800x350x300 | 100 | Q235-A |
| 18 | B18 | Miscella Pump | 1,5 | 1 | 800x350x300 | 100 | Q235-A |
| 19 | B19 | Miscella Pump | 1,5 | 1 | 800x350x300 | 100 | Q235-A |
| 20 | B20 | Conduit Filter | - | 1 | 600x500x1200 | 100 | Q235-A |
| 21 | B21 | Conduit Filter | - | 1 | 600x500x1200 | 100 | Q235-A |
| 22 | B22 | Condenser | - | 1 | 680x316x580 | 250 | 304/Q235-A |
| 23 | B23 | Condenser | - | 1 | 680x316x580 | 250 | 304/Q235-A |
| 24 | B24 | Condenser | - | 1 | 680x316x580 | 250 | 304/Q235-A |
| 25 | B25 | 1# Film Evaporator | - | 1 | 350x200x4500 | 330 | Q235-A |
| 26 | B26 | Flashing Separator | - | 1 | 700x500x1100 | 100 | Q235-A |
| 27 | B27 | 2# Film Evaporator | - | 1 | 150x100x4500 | 150 | Q235-A |
| 28 | B28 | Disk Stripper Column | - | 1 | 250x250x7000 | 350 | Q235-A |
| 29 | B29 | Condenser | - | 1 | 680x316x580 | 200 | 304/Q235-A |
| 30 | B30 | Condenser | - | 1 | 680x316x580 | 200 | 304/Q235-A |
| 31 | B31 | Vacuum Pump | - | 1 | 250x150x1000 | 50 | Q235-A |
| 32 | B32 | Vacuum Pump | - | 1 | 350x150x1000 | 50 | Q235-A |
| 33 | B33 | Miscella Salt Solution Tank | - | 1 | 700x500x3000 | 150 | Q235-A |
| 34 | B34 | Miscella Oil Tank | - | 1 | 700x500x3000 | 150 | Q235-A |
| 35 | B35 | Crude Oil Pump | 1,1 | 1 | 800x350x300 | 100 | Q235-A |
| 36 | B36 | Crude Oil Tank | - | 1 | 800x350x300 | 40 | Q235-A |
| 37 | B37 | Crude Oil Pump | 1,1 | 1 | 800x350x300 | 100 | Q235-A |
| 38 | B38 | Solvent Pump | 1,5 | 1 | 800x350x300 | 100 | Q235-A |
| 39 | B39 | Water Divide Tank | - | 1 | 1200x800x1500 | 500 | 304 |
| 40 | B40 | Turnover Tank | - | 1 | 1200x1200x1200 | 400 | 304 |
| 41 | B41 | Solvent Pump | 1,5 | 1 | 800x350x300 | 200 | 304 |
| 42 | B42 | Hot Water Circulating Pump | - | 1 | 800x600x1500 | 300 | Q235-A |
| 43 | B43 | Water Boiling Tank | - | 1 | 800x600x1500 | 300 | Q235-A |
| 44 | B44 | Feed Hopper | - | 1 | 1400x800x1200 | 200 | Q235-A |
| 45 | - | Bucket Elevator | 0,75 | 1 | 800x300x900 | 400 | Q235-A |
| 46 | - | Screw Conveyor | 2,2 | 1 | 8000x300x400 | 500 | Q235-A |
| 47 | - | Discharge Vehicle | - | 1 | 2000x1200x1000 | 300 | Q235-A |
| TOTAL | 23,15 | 47 | 11370 | ||||
